Suction Lifter - handling, lifting heavy loads
Features of the Suction Cup Lifter
This vacuum lifter is equipped with a built-in 6 m³/h vacuum pump, operating on 400V/3PH, with the option of integrating a battery for stand-alone use. It is designed for versatile use on various types of surfaces.
Structure and Suction Cups
The spreader bar includes:
-
A 2000 mm main crosspiece
-
Five sliding side crosspieces of 1000 mm each
-
Ten 240 mm round suction cups, sliding with a foam seal, suitable for smooth and structured surfaces
All suction cups can be used separately, providing great flexibility for lifting different loads.
Lifting Capacities
This spreader offers a lifting capacity of:
-
600 kg in horizontal position
-
560 kg in vertical position
Features and Controls
The 90° tilt is electrically controlled, and the vacuum on/off and tilt controls are accessible via a wired remote control. A radio control option is also available for greater ease of use.
Security and Compliance
Like all our products, this lifting beam complies with CE standards and is equipped with a visual and audible alarm box, as well as a vacuum reserve, guaranteeing safe and controlled handling.
